When installing a seat belt where it was not previously installed or if the factory underbody reinforcement plates are damaged or missing it is suggested that an RB1 underbody reinforcement plate with attached weld nut be used to add support to all of the mounting points.

Webbing colors tend to vary from mill run to mill run therefore a match to upholstery or carpet can not be guaranteed.



"On The Seat" Retractable Lap Seat Belt For Bench Seats designed to install on a seat when there is not enough clearance between the side of a seat and an interior side wall where the retractor for a standard retractable lap belt must be mounted.The anchor end fittings on both the retractor side and the buckle end side slide through the space where the seat back and bottom meet and then are bolted to the floor in the same manner as a non-retractable lap belt.

Specifications:
  • The non-retractable buckle end side measures 13" long end to end.
  • The webbing when fully extended from the retractor measures 51" long.
  • All of the plastic pieces are black regardless of the webbing color.
  • One MH2 bolt kit is required per belt for mounting.
  • An L-bracket may be required to adjust the location that the anchor end fitting bolts to the floor.
  • If an L-bracket is being used an additional MH2 bolt kit will mount 2 L-brackets.

    To Order:
  • Call:410-381-6700 8-5 EST Monday-Friday
  • Or use the secure on-line order form located at the end of section.
  • Webbing sample colors can be viewed on-line or ordered on-line or by calling (410)381-6700.

    • Color                            Item Number
Beige                               W8248A
Black                               W8248B
Blue,Dark                           W8248C
Blue,Light/Powder                   W8248W
Blue,Medium                         W8248D
Brown,Dark                          W8248M
Brown,Med/Copper                    W8248H
Charcoal                            W8248U
Gray                                W8248K
Green                               W8248G
Green,Military                      W8248R
Ivory                               W8248Z
Maroon                              W8248P
Orange                              W8248X
Purple                              W8248Q
Red,Bright                          W8248N
Red,Dark                            W8248F
Red,Wine                            W8248T
Saddle                              W8248L
Silver                              W8248J
Tan                                 W8248V
Turquoise,Light                     W8248E
White                               W8248W
Yellow                              W8248Y
Bolt Kit                               MH2
L-Bracket,2"                           RB2
Underbody Reinforcement Plate.Pair.    RB1
    "On The Seat" Retractable Lap Belt Price Color Order
    "On The Seat" -W8248 Series. Requires 1 MH2 Bolt Kit Per Belt For Mounting. $40.00ea
    Bolt Kit-MH2. $2.50ea
    2" L-Bracket-RB2. $2.50ea
    Underbody Reinforcement Plate w/Attached Nut.Pair-RB1. $25.00pr
    Webbing Samples. $00.50ea

    All information detailed within this document is based on information believed to be accurate but accuracy is not guaranteed.All pictures,diagrams and item descriptions are protected property of The Andover Companies,Inc and are not to be duplicated in any manner without written permission.
