Retractable Lap Seat Belt Choices

General Information
  • The belts listed can be used for the driver or passenger side installation and are sold each/per person.
  • The retractor used is an automatic locking(ALR) type which locks when the latch has been pulled to the desired length and released. Once locked, in order to change the length the latch must be released back to the retractor.
  • Always use factory mounting point when possible.
  • If the vehicle was not factory equiped with lap seat belts click Here to see how to retrofit an attachement point.
  • The seat belts listed are universal fit with no electrical wiring and are not guaranteed to fit all applications or to match any interior color.

    Buckle End Selection
  • A buckle end with a plastic sleeve is used in a vehicle with bucket seats to hold the buckle end upright.
  • A buckle end without a plastic sleeve is used in a vehicle with bench type seat so it slides between the seat back and bottom.

    Boot Length Selection
  • If the seat bottom is higher off the floor than normal the 7" retractor boot will raise the height that the latch exits the retractor housing making it easier to reach.If there any question as to which length boot to purchase the 4" retractaor boot is what most installation will require.


    Lap Belt With 4" Long Retractor Boot

    Quantity

    Add Optional Buckle With Black Background And White Push $2.50ea
    Add Mounting Kit With L-Bracket $4.25ea
    Add Additional L-Bracket For Buckle End $2.50ea
    Add Mounting Kit For Additional L-Bracket $1.25ea

    Product Notes:
  • All of the plastic pieces are black regardless of webbing color.
  • The webbing fully extended from the retractor measures 59" Long.
  • The boot is measured from end to end when laying flat.
  • A L-bracket is required to mount the retractor upright.
  • Lengths listed are approximate.
  • The invoice may show different product numbers.
  • Click link at top of page for matching non-retractable seat belts.




    		•

    Lap Belt With 7" Long Retractor Boot

    Quantity

    Add Optional Buckle With Black Background With White Press $2.50ea
    Add Mounting Kit With L-Bracket $4.25ea
    Add Additional L-Bracket For Buckle End $2.50ea
    Add Mounting Kit For Additional L-Bracket $1.25ea

    Product Notes:
  • **Indicates the plastic pieces are color matched to the webbing color.
  • Unless indicated as above all the plastic pieces are black.
  • The webbing fully extended from the retractor measures 59" Long.
  • The boot is measured from end to end when laying flat.
  • A L-bracket is required to mount the retractor upright.
  • Lengths listed are approximate.
  • The invoice may show different product numbers.
  • Click link at top of page for matching non-retractable seat belts.



    • Retractable Lap And Shoulder Harness Seat Belt Choices

    General Information
  • The belts listed can be used for a drivers or passenger side installation and are sold each/per person.
  • The retractors utilized are emergency locking(ELR) type which have an inertia reel which is web sensitive locking the retractor instantly on a sudden movement of the webbing.
  • Always use factory mounting point when possible.
  • The installation of a seat belt with a door post extension requires a reinforced shoulder harness attachement point. If the vehicle was not factory equiped with shoulder harness click Here to see how to retrofit an attachement point.
  • The seat belts listed are universal fit with no electrical wiring and are not guaranteed to fit all applications or to match any interior color.

    Buckle End Selection
  • A buckle end with a plastic sleeve is used in a vehicle with bucket seats to hold the buckle end upright.
  • A buckle end without a plastic sleeve is used in a vehicle with bench type seat so it slides between the seat back and bottom.

    Shoulder Harness Mounting Configuration Selection
  • A harness belt without a door post extension is used in a convertible or when the retractor will be mounted behind the shoulder below the window.
  • A harness belt with a 2 1/2" or a 8 1/2" door post extension in a matter of preference. The 8 1/2" door post extension is mostly used when the harness mounting point is higher than in a normal passenger which lowers the webbing making the position that it comes across the neck more comfortable.

    Length Selection
  • 110" is the most common fully extended length when the seat belt being installed has 2 1/2" door post extension and the harness mounting bracket is located below the window or the vehicle does not have a door post above the lower part of the window.
  • 140" is the most common fully extended length when the seat belt being installed has a 2 1/2" or 8 1/2" door post extension and the harness mounting bracket is located on the roof or above the window on a door post.


    Lap Belt With Shoulder Harness
    -With 12" Long Non-Sleeved Buckle End-

    Extended Lenght Choices
  • 85" Long: 5" Of Webbing Outside Of Retractor When Fully Retracted.
  • 110" Long: 30" Of Webbing Outside Of Retractor When Fully Retracted.
  • 125" Long: 45" Of Webbing Outside Of Retractor When Fully Retracted.
  • 140" Long: 60" Of Webbing Outside Of Retractor When Fully Retracted.
    Quantity
    Add Optional Buckle With Black Background With White Press $2.50ea
    Add Mounting Kit With L-Bracket And Shoulder Bolt $5.25ea
    Add Additional L-Bracket For Buckle End $2.50ea
    Add Mounting Kit For Additional L-Bracket $1.25ea

    Product Notes:
  • **Indicates the plastic pieces are color matched to the webbing color.
  • Unless indicated as above all the plastic pieces are black.
  • The buckle end included is 12" long without a sleeve.
  • A L-bracket is required to mount the retractor upright.
  • Lengths listed are approximate.
  • The invoice may show different product numbers.
  • Click link at top of page for matching non-retractable seat belts.




    		•

    Lap Belt With Shoulder Harness
    -With 20" Long Non-Sleeved Buckle End-

    Extended Lenght Choices
  • 85" Long:5" Of Webbing Outside Of Retractor When Fully Retracted.
  • 110" Long:30" Of Webbing Outside Of Retractor When Fully Retracted.
  • 125" Long:45" Of Webbing Outside Of Retractor When Fully Retracted.
  • 140" Long:60" Of Webbing Outside Of Retractor When Fully Retracted.
    Quantity
    Add Optional Buckle With Black Background With White Press $2.50ea
    Add Mounting Kit With L-Bracket And Shoulder Bolt $5.25ea
    Add Additional L-Bracket For Buckle End $2.50ea
    Add Mounting Kit For Additional L-Bracket $1.25ea

    Product Notes:
  • **Indicates the plastic pieces are color matched to the webbing color.
  • Unless indicated as above all the plastic pieces are black.
  • The buckle end included is 20" long without a sleeve.
  • A L-bracket is required to mount the retractor upright.
  • Lengths listed are approximate.
  • The invoice may show different product numbers.
  • Click link at top of page for matching non-retractable seat belts.




    		•

    Lap Belt With Shoulder Harness
    -With 12" Long Sleeved Buckle End-

    Extended Lenght Choices
  • 85" Long:5" Of Webbing Outside Of Retractor When Fully Retracted.
  • 110" Long:30" Of Webbing Outside Of Retractor When Fully Retracted.
  • 125" Long:45" Of Webbing Outside Of Retractor When Fully Retracted.
  • 140" Long:60" Of Webbing Outside Of Retractor When Fully Retracted.
    Quantity
    Add Optional Buckle With Black Background With White Press $2.50ea
    Add Mounting Kit With L-Bracket And Shoulder Bolt $5.25ea
    Add Additional L-Bracket For Buckle End $2.50ea
    Add Mounting Kit For Additional L-Bracket $1.25ea

    Product Notes:
  • **Indicates the plastic pieces are color matched to the webbing color.
  • Unless indicated as above all the plastic pieces are black.
  • The buckle end included is 12" long with a hard plastic sleeve.
  • A L-bracket is required to mount the retractor upright.
  • Lengths listed are approximate.
  • The invoice may show different product numbers.




    		•

    Lap With Shoulder Harness With Dual Retractors

    Quantity

    Add Optional Buckle With Black Background With White Press $2.50ea
    Add Mounting Kit With L-Bracket And Shoulder Bolt $5.25ea
    Add Additional L-Bracket For Buckle End $2.50ea
    Add Mounting Kit For Additional L-Bracket $1.25ea

    Product Notes:
  • All of the plastic pieces are black regardless of webbing color.
  • The webbing fully extended from the lap retractor measures 55" Long.
  • The webbing fully extended from the harness retractor measures 65" Long.
  • The lap retractor is an (ALR) automatic locking type.
  • The harness retractor is an (ELR) emergengency locking type.
  • A L-bracket is required to mount the retractor upright.
  • Lengths listed are approximate.
  • The invoice may show different product numbers.



    • Mounting Brackets

    Quantity:
    Mounting Kit If Belt Mounting Kit Was Purchased. $1.25ea
    Mounting Kit If Belt Mounting Kit Was Not Purchased. $2.50ea

    Product Notes:
  • RB6: 1 1/2" long L-bracket.Gold chromate color.
  • RB2: 2" long L-bracket.Gold chromate color.
  • RB9: 5" long double angle bracket.Gold chromate color.
  • RB8: 7" long single angle bracket.Gold Chromate color.
  • RB7: 3" long flat extension.Gold chromate color.
  • RB11: 6" long flat extension.Gold chromate color.
  • RB10: 12" long single angle bracket.Gold chromate color.

    • Reinforcement Plates

    Quantity:
    Add Mounting Bolt $1.00ea

    Product Notes:
  • RB1: Curved steel with attached nut.Measures 4 1/2" x 3".
  • RB3: Steel with attached nut.Measures 4 1/2"(not including tip) x 1 1/2".
  • RB4: Measures 3" x 1 1/2" and accepts a 7/16th fine thread bolt.


    • (SBL9-1 5-30-09)
