1968-71 Corvette Seat Belts

1968, 1969, 1970 and 1971 Chevrolet Corvette replacement non retractable lap seat belts and retractable lap seat belts that are available with or with out the optional add-on shoulder harness. The buckle styles available are a standard push button and a all metal OEM style push button.The lap seat belt retractors are automatic locking (ALR) which lock in place when pulled in to position and released. The shoulder harness retractors are web sensitive emergency locking (ELR) which allow for some movement once attached to the lap seat belt stud and will lock on sudden movement or a pre-designed tension.

All of the seat belts and related hardware listed are new and manufactured to meet or exceed FMVSS (U.S. Federal Motor Vehicle Safety Standards) 209,302 and SAE 386 with most manufactured or assembled in the USA..

Also available are 1968-71 retrofit kits that include an attached combination retractable lap seat belt with shoulder harness and include mounting hardware and installation instructions. Contact us for additional information.


1968, 1969, 1970 and 1971 Corvette replacement non retractable lap seat belts sized to fit a Corvette. These are not a universal fit seat belt where the non adjustable inner buckle side is to long making it difficult to tighten. The adjustable side of these Corvette replacement seat belts, when fully extended measures approximately 53" long and will adjust down to 5" long and include an inner buckle side that measures approximately 9" long with the webbing covered with a hard plastic sleeve like the 1969-71 original configuration.

  • *Prior to the part number indicates all plastic pieces are color matched to the webbing.Unless indicated all the plastic pieces are black.
  • Does not include a provision to add a shoulder harness.
  • Can be used as a 1968 replacement.

    Mounting Hardware Information;
  • If a factory underbody reinforcing plate is damaged or missing order one 201K retrofit mounting kit which includes universal underbody reinforcing plates and mounting bolts per lap seat belt.

    To Order:
  • Call:(302) 629-8508 8-5 EST Monday-Friday
  • Or use the secure on-line order form below.

    • Webbing colors vary from mill run to mill run therefore a match to an existing seat belt, upholstery or carpet color is not be guaranteed. If a color match is critical it is suggested that a webbing sample be ordered. To view webbing colors or to order webbing samples click on the color name. In addition to the webbing colors listed these seat belts can be ordered with any webbing color that is shown on the Additional Webbing Colors page as a non returnable special order.
    Color                      Item Number
Black-B                      *W8126B
Blue,Bright                     N/A
Blue,Dark-C                  *W8126C
Green-G                       W8126G
Red-N                        *W8126N
Saddle-L                     *W8126L
    1968-71 Non Retractable Replacement Lap Seat Belt Price
    Non Retractable Lap Belt-W8126 Series.Per Seat. $25.00ea
    Retrofit Mounting Kit-201K.One Per Lap Seat Belt. $11.00ea



    1968 and 1969 Replacement Car Sets. Non retractable lap seat belt car set that includes the lap seat belt for the driver and passenger with a stud provision on the latch end to add an optional retractable shoulder harness.

  • Uses the factory mounting configuration and mounting locations.
  • The lap seat belts can not be used with a factory original Corvette shoulder harness.
  • The inner buckle side is 12" long with the webbing covered with a hard plastic sleeve.
  • The add-on shoulder harness listed is not compatible with an original Corvette lap seat belt.
  • On a 1969 when not re-using an original web stop which was installed after the shoulder harness end was feed thru the seat back a black, paint to match the interior web stop boot is available.
  • The buckle, buckle side webbing sleeve and all plastic pieces are black regardless of the webbing color.

    Mounting Hardware Information
  • If a factory lap seat belt underbody reinforcing plate is damaged or missing order one 201K-2 retrofit mounting kit which includes universal underbody reinforcing plates and mounting bolts per car set.
  • When re-using the factory lap seat belt underbody reinforcing plates order one 8200 bolt kit per car set.
  • If a factory shoulder harness underbody reinforcing plate is damaged or missing order one RB4 universal reinforcing plate and one MH1-1 bolt per shoulder harness.
  • When re-using the factory shoulder harness underbody reinforcing plate order one 8189 bolt per shoulder harness.

    To Order:
  • Call:(302)629-8508 8-5 EST Monday-Friday
  • Or use the secure on-line order form below.

    • Webbing colors vary from mill run to mill run therefore a match to an existing seat belt, upholstery or carpet color is not be guaranteed. If a color match is critical it is suggested that a webbing sample be ordered. To view webbing colors or to order webbing samples click on the color name. In addition to the webbing colors listed these seat belts can be ordered with any webbing color that is shown on the Additional Webbing Colors page as a non returnable special order.
    Color               Lap Belt Car Set      Shoulder Harness(Two Required)
Black-B                  W8217B                     W8219B
Blue,Dark-C              W8217C                     W8219C
Green-G                  W8217G                     W8219G
Red-N                    W8217N                     W8219N
Saddle-L                 W8217L                     W8219L

    1968-69 Replacement Seat Belts Price
    1968-69 Lap Belt Car Set.-W8217 Series. Black:$100.00 Colors+10.00
    Shoulder Harness-W8219 Series.Use With 8217 Series Seat Belts Only.Two Required. Black:$50.00 Colors+5.00
    Shoulder Harness Web Stop Boot-W8170-01 Series. $12.50ea
    Retrofit Mounting Kit-201K-2.One Per Lap Car Set. $22.00ea
    1969 Lap Belt Car Set Mounting Kit-8200.Use With Factory Underbody Reinforcing Plates.One Per Car Set. $6.50ea
    Bolt For Shoulder Harness-8189.Use With Factory Underbody Reinforcing Plates.One Per Shoulder Harness. $2.00ea
    Shoulder Harness Replacement Reinforcing Plate-RB4.One Per Shoulder Harness.Order 1 MH1-1 Bolt Per Plate. $7.50ea
    Shoulder Harness Mounting Bolt-MH1-1.Use With RB4 Reinforcing Plate.One Per Plate. $1.00ea



    1970 and 1971 Replacement Car Sets.Non retractable lap seat belt car set that includes the lap seat belt for the driver and passenger with the stud provision on the latch end to add an optional retractable shoulder harness.Also available per seat. Call for information. See the partial components and related section at the end of the page for shoulder harness assemblies and related items that are compatible with factory original Corvette seat belts.

  • Uses the factory configuration and mounting locations.
  • The lap seat belts are not compatible with an original Corvette shoulder harness.
  • The shoulder harness is not compatible with an original Corvette lap seat belt.
  • The non-adjustable inner buckle side is 9" long with the webbing covered with a hard plastic sleeve.
  • If not re-using the web stop boot that was installed after the shoulder harness end was feed thru the seat back a black, paint to match the interior, web stop boot is available.
  • The buckle, buckle side webbing sleeve and all the plastic pieces are black regardless of the webbing color.

    Mounting Hardware Information
  • If a factory lap seat belt underbody reinforcing plate is damaged or missing order one 201K-2 retrofit mounting kit which includes universal underbody reinforcing plates and mounting bolts per lap seat belt car set.
  • When re-using the factory lap seat belt underbody reinforcing plates order one 8224 bolt kit per car set.
  • If a factory shoulder harness underbody reinforcing plate is damaged or missing order one RB4 universal reinforcing plate and one MH1-1 bolt per shoulder harness.
  • When re-using a factory shoulder harness underbody reinforcing plates order one 8189 bolt per shoulder harness.

    To Order:
  • Call:(302)629-8508 8-5 EST Monday-Friday
  • Or use the secure on-line order form below.

    • Webbing colors vary from mill run to mill run therefore a match to an existing seat belt, upholstery or carpet color is not be guaranteed. If a color match is critical it is suggested that a webbing sample be ordered. To view webbing colors or to order webbing samples click on the color name. In addition to the webbing colors listed these seat belts can be ordered with any webbing color that is shown on the Additional Webbing Colors page as a non returnable special order.
    Color                     Lap Belt Car Set      Shoulder Harness(Two Required)
Blue,Bright                    N/A                         N/A
Black-B                      W8218B                       W8219B
Blue,Dark-C                  W8218C                       W8219C
Green-G                      W8218G                       W8219C
Red-N                        W8218N                       W8219N
Saddle,Dark                   N/A                          N/A
Saddle,Light-L               W8218L                       W8219L
    1970-71 Replacement Seat Belts Price
    1970-71 Lap Belt Car Set.-W8218 Series. Black:$100.00 Colors+10.00
    1970-71 Shoulder Harness-W8219 Series.Use With W8218 Series Car Set Only.Two Required. Black:$50.00 Colors+5.00
    Shoulder Harness Web Stop Boot-W8170-01.One Per Shoulder Harness. $12.50ea
    Retrofit Mounting Kit-201K-2. One Per Lap Belt Car Set. $22.00ea
    1970-71 Lap Belt Car Set Mounting Kit-8224.Use With Factory Underbody Reinforcing Plates.One Per Car Set. $9.25ea
    Shoulder Harness Bolt-8189.Use With Factory Reinforcing Plates.One Per Shoulder Harness. $2.00ea
    Shoulder Harness Replacement Reinforcing Plate-RB4.One Per Shoulder Harness.One MH1-1 Bolt Per Plate. $7.50ea
    Shoulder Harness Mounting Bolt-MH1-1.Use With RB4 Reinforcing Plate.One Per Plate. $1.00ea


    Partial Components And Related

    The following 1968-71 partial sets and related items are compatible with factory original Corvette seat belts and factory original underbody reinforcing plates.

    8128 Shoulder Harness Information
  • Has the provision on the chrome end to attach to the stud on an original Corvette latch end.
  • Can be used to add the optional shoulder harness(A85 option) to a original Corvette lap seat belt.
  • Can be used to replace a damaged original 1970-71 shoulder harness.
  • When not re-using the original web stop boot which was installed after the shoulder harness end was feed thru the seat back,a black paint to match the interior, web stop boot is available.

    Mounting Hardware Information
  • The mounting hardware listed is replacement style and for use with factory underbody reinforcing plates only.
  • A car set mounting kit installs both the driver and passenger side seat belts.

    Misc Information
  • The original GM buckle side is available with our without the webbing cover sleeve.
  • Retractors listed as bare can be used as a replacement if an original retractor is damaged and the original webbing is to be re-used. A small amount of webbing is on the retractor to maintain the tension. The webbing, web stop boot and latch end chrome are not included. Sold not returnable.



    To Order:
  • Call:(302) 629-8508 8-5 EST Monday-Friday
  • Or use the secure on-line order form below.

    • A match to an existing seat belt, upholstery or carpet color is not be guaranteed. If a color match is critical it is suggested that a webbing sample be ordered. To view webbing colors or to order webbing samples click on the color name. In addition to the webbing colors listed these seat belts can be ordered with any webbing color that is shown on the Additional Webbing Colors page as a non returnable special order.
    Year      Item Number    Description
1970-71      8000-NC    Buckle End Side With GM Buckle Without Webbing Sleeve.
1970-71      8000-01    Buckle End Side With GM Buckle With 8170-01 Webbing Sleeve.
1970-71      8172-01    Buckle Side Webbing Sleeve.Black.
1970-71      CR4        Retractor Bare.Shoulder Harness. ELR Web Sensitive.
1970-71      8170-01    Shoulder Harness Web Stop Boot.Black.
1970-71      Call       Shoulder Harness Web Stop Boot.Dark Saddle.
1970-71      Call       Shoulder Harness Web Stop Boot. Green.
1970-71      Call       Shoulder Harness Web Stop Boot. Medium Saddle.
1970-71      Call       Shoulder Harness Web Stop Boot. Red.
1970-71      8128-01    Shoulder Harness,Black.
1970-71      8128-13    Shoulder Harness.Light Saddle.
1970-71      Call       Shoulder Harness.Green.
1970-71      8128-15    Shoulder Harness.Dark Saddle.
1970-71      8128-10    Shoulder Harness.Red.
1970-71      LE1        Shoulder Harness To Latch End Connection.Chrome.



Mounting Hardware
1968         8225       Lap Belt Car Set Mounting Kit With Allen Head Bolts.
1968         8196       Lap Belt With Shoulder Harness Car Set Mounting Kit With Allen Head Bolts.
1968         8214       Bolt Lap Or Shoulder Harness Mounting Bolt.Each. Allen Head.
1969         8200       Lap Belt Car Set Mounting Kit.
1969         8193       Lap Belt With Shoulder Harness Car Set Mounting Kit.
1970-71      8224       Lap Belt Car Set Mounting Kit.
1970-71      8188       Lap Belt With Shoulder Harness Car Set Mounting Kit.
1970-71      8189       Shoulder Harness Mounting Bolt.Per Harness.
1968-71      RB1-1      Replacement Underbody Reinforcement Plate With Weld Nut.Each
1968-71      MH1-1      Bolt. Use With RB1-1 Reinforcing Plate.One per Plate.
    Partial Components And Related Price
    Shoulder Harness-W8128 Series. Web Stop Boot Not Included Black $65.00ea Colors+$10.00
    Shoulder Harness Bare Retractor-CR4.ELR Web Sensitive. $50.00ea
    Buckle Side With GM Buckle Without Sleeve-W8000-NC. $45.00ea
    Buckle Side With GM Buckle With Sleeve W8000-01. $55.00ea
    Shoulder Harness Web Stop Boot-W8170-01 Series.Use With W8128 Series Shoulder Harness. $12.50ea
    Buckle Side Webbing Sleeve-W8172-01 Series. $16.25ea
    Bolt-8214.1968 Lap Belt Or Shoulder Harness Mounting.Allen Head. $4.25ea
    1968 Lap Belt Car Set Mounting Kit-8225. $10.00ea
    1968 Lap Belt With Shoulder Harness Car Set Mounting Kit-8196. $15.00ea
    1969 Lap Belt Car Set Mounting Kit.-8200 $6.00ea
    1969 Lap Belt With Shoulder Harness Car Set Mounting Kit-8193. $10.00ea
    1970-71 Lap Belt Car Set Mounting Kit-8224. $9.25ea
    1970-71 Lap Belt Car Set With Shoulder Harness Mounting Kit-8188. $12.50ea
    1970-71 Shoulder Harness Bolt-8189. $2.00ea
    Underbody Reinforcement Plate-RB1-1 With Attached Weld Nut.Each. $14.50ea
    Bolt-MH1-1. Use With RB1-1 Reinforcing Plate. One Per Plate. $1.00ea

    Liability Disclaimer:The Andover Companies, and its subsidiaries assumes no responsibility for any damage due to the installation, either proper or improper, or for any damage or bodily injury arising from the use of any product. It is understood that the purchaser, installer and/or end user is responsible for the determination that the product purchased is suitable for its intended use and agrees to indemnify and hold The Andover Companies,Inc and its subsidiaries, harmless for any claim, action or demand arising from the installation and/or use of any product. There are no guarantees or warrantees on any product, implied or expressed, of fitness for a particular use with any such warrantees being specifically and expressly disclaimed. In the event any of the above limitations are held not enforceable our liability shall not exceed an amount equal to the amount paid to us for the product. Receipt of product or products confirm acceptance of disclaimer and liability transfer to purchaser, installer and/or end user.

    All information detailed within this document is based on information believed to be accurate but accuracy is not guaranteed.All pictures,diagrams and item descriptions are protected property of The Andover Companies,Inc and are not to be duplicated in any manner without written permission.
